• Increases load capacity
  • Allows for 14" tire upgrades on most trailers
  • Allows for transportation of larger machines



ONLY AVAILABLE AT TIME OF TRAILER PURCHASE OR AS REPLACEMENT
As ATV's grow every year so does the demand for a sturdy platform on witch to transport them. For most ATV's the Echo Elite standard axle is enough. But for some who buy the biggest ATV's on the market they might need a little extra support. With the Echo Elite 3500LB Axle upgrade you have a great solution. Not only does this give you the abilty to carry more on your load but also allows for you to upgrade you tires form 13" tires to 14" tires which also increased your load capacity.

ECHO 2-3/8" diameter round tube trailer axle has a black painted finish and cambered design. All axles include spindle nuts, nut retainers, D-washers, and spring seats (seats need to be welded to complete installation). CAMBER: Axles are cambered or 'road set' so there is a bow until weight is put on the axle. All cambered axles should be mounted with the center bow up. This axle includes pre-attached brake mounting flanges (4-hole). Flange mounting holes are on 2-7/8" centers.

Axle Type: Round/Straight
Load Rating: 3500 lbs.
Track Length: Varies
Spring Center: Varies
Overall Length: Varies
Spindle Size: 1-3/8" x 1-1/16" EZ-Lube Spindles
3500 Lb Trailer Axle
Varies
Black
Steel Construction
Manufacturer Warranty
Varies
Varies
Varies
Varies
Easy Lube Spindles Standard
