Rectangle Tail Light
Model:ID-86010-R
Sealed Oval Stop, Turn & Tail Light
Model: TL-63010-RK
  • Sealed 6" oval stop, turn and tail, red
  • Can be used on roadside or curbside of vehicle or trailer
  • Kit includes light, grommet, and wire plug
  • Fits most competitive oval lights
  • Popular on commercial market vehicles
Red Square Clearence/ Side Marker Light
Model:  # MR2020R
Lighted Licence Plate Bracket
Model: P# lti-43010-k
  • Designed for 12-volt systems
  • Flange Mount
  • 2 1/2" Diameter Amber Lens
  • Mounts With Tension Ring
  • flush-mount rubber grommet
  • Submersible












Light Harness


25" - 30" Wiring Harness
Model: WW-70025-4
Seven Prong Trailer Connection
Model: WRV 7000-1
Center Light Bar
Model: ID-86010-R
  • Amber, square light functions as clearance, side marker light
  • Reflector lens is DOT compliant, eliminating separate reflector
  • Weather and corrosion resistant
  • Single-wire design grounds through the mounting stud
  • Dimensions: 2-3/4" L x 2-1/8" W x 1" D
  • Sonic Sealed
Red Square Clearence/ Side Marker Light
Model:  # MR2020R
  • Amber, square light functions as clearance, side marker light
  • Reflector lens is DOT compliant, eliminating separate reflector
  • Weather and corrosion resistant
  • Single-wire design grounds through the mounting stud
  • Dimensions: 2-3/4" L x 2-1/8" W x 1" D
  • Sonic Sealed
Round Amber 2 1/2  Marker Light
Model: CL-26010-AK
Round Red 2 1/2  Marker Light
Model: CL-26010-RK
  • Under 80" Combination Tail Lights
  • Combination Stop, Turn & Tail Light
  • High Impact housing with acrylic lens
  • Side marker light w/ reflector
  • license plate illuminator ( Street Side )
  • Designed for 12-volt systems
  • Flange Mount
  • 2 1/2" Diameter Red Lens
  • Mounts With Tension Ring
  • flush-mount rubber grommet
  • Submersible
  • Works With Small Or Large Plates
  • Rust Proof Black Polymer
  • bright light for illumination
  • Single Wire Design
  • Replaceable bulb
  • Bracket Included

Square Tail Light With Side Reflector
Model: CL-43010-A
Square Amber Side Marker Light
Model: 153KA2-A
Square Amber Side Marker Light
Model: 153KA2-R
  • Functions Clearance/Side Marker
  • Includes Grommet & Plug
  • Color: Amber
  • 2 Diodes
  • Depth: 7/8"
  • Length: 2-1/2"
  • Height: 1-3/16"
  • Functions Clearance/Side Marker
  • Includes Grommet & Plug
  • Color: Red
  • 2 Diodes
  • Depth: 7/8"
  • Length: 2-1/2"
  • Height: 1-3/16"
  • Stainless steel frame
  • Capacity: 12 V
  • Optic-free lens
  • 15" lead wire
  • Diodes: 9
  • PC plastic housing
  • Color: red


Four Flat Trailer Connection
Model: WRV 7000-1
  • 20' Split Wishbone
  • 4-Way Trailer Wiring
  • 30" Ground Wire
  • Four Conductors
  • 4 Flat Connector
  • 18 Gauge Wire

  • 4" Wire Lead
  • Interchangeable
  • Auxiliary Electrical Line
  • Wires Are Color Coded
  • Male & Female Ends Available
  • Contoured Molding For A Secure Grip
  • Available Both Socket/Vehicle Ends
  • Plug and Play T-harnesses
  • Innovative designed one-piece
  • Quick and easy to install
  • Manufactured from Nylon
  • Design Incorporates Dual Handles

  • Ideal For boat and PWC trailers
  • Used On Trailers less Than 80" wide.
  • Fully Gasketed
  • Easy Bulb Replacement.
  • Prewired For Easy Installation.
  • 6-Function, Right/Curbside
  • 5.25" x 4.66" x 3.76" overall height


Rectangle Amber Side Marker Light
Model: CL-46011-A
  • Reflectorized lens is DOT compliant
  • Weather & Corrosion Resistant
  • Replaceable lens
  • Surface Mounts On 3" Centers
  • Two-Wire Design Includes Lead & Ground Wires
  • Dimensions: 4" L x 1-1/2" W x 15/16" D
  • Light draws 0.054 amps at 12.8 volts
Rectangle Light
Oval Light
Square Light
Square Light
five light
Licence Plate Light
Round Light
Rectangle Light Amber
Rectangle Light Red
Rectangle Light Amber Reflector
Bar Light
Four Flat Connector
Seven Prong Connector
Round Light
